Szczegóły Produktu:
Zapłata:
|
| Refrigerant: | R404A/R507 | Type: | Expansion Valve |
|---|---|---|---|
| Export Markets: | Global | Application: | Refrigeration Parts |
| Material: | Brass | Valve Type: | Angleway |
| Temperature: | -40/+10 | Max pressure: | 28 bar |
| Evaporating temperature: | –60°C - +10°C | Mop: | no mop |
| Weight: | 0.88 | ||
| High Light: | refrigeration and air conditioning tools and equipment,danfoss expansion valve |
||
Tes55 Series R404a / R507 / - 40 ℃ Valves 067g3301 , 5m
Specifications:
TES55 R404A - R507 thermostatic expansion valve
range "N" -40°C to +10°C without MOP nr.067G3301
More information please check below file:
|
Type
|
TES 55 |
| Weight | 0.703 [kg] |
| Approvals | GOST R |
| Capillary tube length [in] | 197.0 in |
| Length. capillary tube [mm] | 5,000 mm |
| EAN number | 5.70243E+12 |
| Port Type equalization | Folder |
| Size equalization [in] | 1/4 IN |
| Maximum operating pressure [bar] | 28.0 bar |
| Max operating pressure | 400 psig |
| Packaging Format | Multi pack |
| Product Description | Espans valve. thermostatic |
| Quantia Packaging | 1 pcs |
| Refrigerant (s) | R404A/R507 |
| Operating temp. | -40 - 10 ° C |
| Temperature range [° F] | -40 - 50 ° F |
| Type | Element |
| R404A | ||||||||
| Model | Balance pipe | Capillary | Code No. | |||||
| N Series | NM Series | NL Series | Bseries | |||||
| 6 mm | m | No MOP | MOP +15℃ | MOP +0℃ | MOP -10℃ | No MOP | MOP -20℃ | |
| TES5 | External balance | 3 | 067B3342 | 067B3357 | 067B3358 | 067B3344 | 067B3343 | |
| TES12 | 3 | 067B3347 | 067B3345 | 067B3348 | 067B3349 | |||
| 5 | 067B3346 | 067B3350 | ||||||
| TES20 | 3 | 067B3352 | 067B3351 | 067B3353 | 067B3354 | |||
| 5 | 067B3356 | 067B3355 | ||||||
| TES55 | 3 | 067G3302 | 067G3303 | 067G3304 | 067G3305 | |||
| 5 | 067G3301 | 067G3306 | ||||||
| Refrigerant | Model | equalizer | Capillary | Connection size | code | ||||
| inlet×outlet | N series -40+10 |
N series -40-5 |
NL series -40-15 |
||||||
| m | in.×in. | mm×mm | Without mop | With mop | Without mop | With mop | |||
| R22 | TX 2 | internal | 1.5 | 3/8*1/2 | 10*12 | 068Z3206 | 068Z3208 | 068Z3224 | 068Z3226 |
| TEX 2 | external | 1.5 | 3/8*1/2 | 10*12 | 068Z3209 | 068Z3211 | 068Z3225 | 068Z3227 | |
| R134a | TN 2 | internal | 1.5 | 3/8*1/2 | 10*12 | 068Z3346 | 068Z3347 | 068Z3393 | 068Z3369 |
| TEN 2 | external | 1.5 | 3/8*1/2 | 10*12 | 068Z3348 | 068Z3349 | 068Z3392 | 068Z3370 | |
| R404A /R507 |
TS 2 | internal | 1.5 | 3/8*1/2 | 10*12 | 068Z3400 | 068Z3402 | 068Z3406 | 068Z3408 |
| TES 2 | external | 1.5 | 3/8*1/2 | 10*12 | 068Z3403 | 068Z3405 | 068Z3407 | 068Z3409 | |
| R12 | TF 2 | internal | 1.5 | 3/8*1/2 | 10*12 | 068Z3202 | 068Z3236 | 068Z3220 | 068Z3222 |
| TEF 2 | external | 1.5 | 3/8*1/2 | 10*12 | 068Z3204 | 068Z3237 | 068Z3221 | 068Z3223 | |
| R502 | TY 2 | internal | 1.5 | 3/8*1/2 | 10*12 | 068Z3212 | 068Z3214 | 068Z3230 | 068Z3232 |
| TEY 2 | external | 1.5 | 3/8*1/2 | 10*12 | 068Z3215 | 068Z3217 | 068Z3231 | 068Z3233 |
|
| Expansion Valve | |
| Code | Type |
| T2 | |
| 068-2002 | Orifice assembly number0X |
| 068-2003 | Orifice assembly number00 |
| 068-2090 | Orifice assembly number00 |
| 068-2010 | Orifice assembly number01 |
| 068-2091 | Orifice assembly number01 |
| 068-2015 | Orifice assembly number02 |
| 068-2092 | Orifice assembly number02 |
| 068-2006 | Orifice assembly number03 |
| 068-2093 | Orifice assembly number03 |
| 068-2007 | Orifice assembly number04 |
| 068-2094 | Orifice assembly number04 |
| 068-2008 | Orifice assembly number05 |
| 068-2095 | Orifice assembly number05 |
| 068-2009 | Orifice assembly number06 |
| 068-2096 | Orifice assembly number06 |
| 068-2089 | Orifice assembly number0X |
| 068Z7008 | TEB 2 flare×flare connection |
| 068Z7009 | TEB 2 flare×flare connection |
| 068Z3174 | TEB 2 flare×solder connection |
| 068Z3518 | TEB 2 flare×solder connection |
| 068Z7012 | TEB 2 flare×solder connection |
| 068Z3348 | TEN 2 flare×flare connection |
| 068Z3349 | TEN 2 flare×flare connection |
| 068Z3370 | TEN 2 flare×flare connection |
| 068Z3392 | TEN 2 flare×flare connection |
| 068Z3385 | TEN 2 flare×solder connection |
| 068Z3386 | TEN 2 flare×solder connection |
| 068Z3389 | TEN 2 flare×solder connection |
| 068Z3390 | TEN 2 flare×solder connection |
| 068Z3403 | TES 2 flare×flare connection |
| 068Z3404 | TES 2 flare×flare connection |
| 068Z3405 | TES 2 flare×flare connection |
| 068Z3407 | TES 2 flare×flare connection |
| 068Z3409 | TES 2 flare×flare connection |
| 068Z3411 | TES 2 flare×flare connection |
| 068Z3415 | TES 2 flare×solder connection |
| 068Z3417 | TES 2 flare×solder connection |
| 068Z3419 | TES 2 flare×solder connection |
| 068Z3421 | TES 2 flare×solder connection |
| 068Z3422 | TES 2 flare×solder connection |
| 068Z3424 | TES 2 flare×solder connection |
| 068Z3426 | TES 2 flare×solder connection |
| 068Z3428 | TES 2 flare×solder connection |
| 068Z3430 | TES 2 flare×solder connection |
| 068Z3437 | TES 2 flare×solder connection |
| 068Z3209 | TEX 2 flare×flare connection |
| 068Z3210 | TEX 2 flare×flare connection |
| 068Z3211 | TEX 2 flare×flare connection |
| 068Z3225 | TEX 2 flare×flare connection |
| 068Z3227 | TEX 2 flare×flare connection |
| 068Z3229 | TEX 2 flare×flare connection |
| 068Z3277 | TEX 2 flare×solder connection |
| 068Z3284 | TEX 2 flare×solder connection |
| 068Z3290 | TEX 2 flare×solder connection |
| Expansion Valve | |
| Code | Type |
| 068Z3305 | TEX 2 flare×solder connection |
| 068Z3311 | TEX 2 flare×solder connection |
| 068Z3320 | TEX 2 flare×solder connection |
| 068Z3359 | TEX 2 flare×solder connection |
| 068Z3363 | TEX 2 flare×solder connection |
| 068Z3367 | TEX 2 flare×solder connection |
| 068Z3501 | TEZ 2 flare×flare connection |
| 068Z3517 | TEZ 2 flare×flare connection |
| 068Z3446 | TEZ 2 flare×solder connection |
| 068Z3447 | TEZ 2 flare×solder connection |
| 068Z3503 | TEZ 2 flare×solder connection |
| 068Z3515 | TEZ 2 flare×solder connection |
| 068Z3346 | TN 2 flare×flare connection |
| 068Z3347 | TN 2 flare×flare connection |
| 068Z3369 | TN 2 flare×flare connection |
| 068Z3393 | TN 2 flare×flare connection |
| 068Z3383 | TN 2 flare×solder connection |
| 068Z3384 | TN 2 flare×solder connection |
| 068Z3387 | TN 2 flare×solder connection |
| 068Z3388 | TN 2 flare×solder connection |
| 068Z3400 | TS 2 flare×flare connection |
| 068Z3401 | TS 2 flare×flare connection |
| 068Z3402 | TS 2 flare×flare connection |
| 068Z3406 | TS 2 flare×flare connection |
| 068Z3408 | TS 2 flare×flare connection |
| 068Z3410 | TS 2 flare×flare connection |
| 068Z3414 | TS 2 flare×solder connection |
| 068Z3416 | TS 2 flare×solder connection |
| 068Z3418 | TS 2 flare×solder connection |
| 068Z3420 | TS 2 flare×solder connection |
| 068Z3423 | TS 2 flare×solder connection |
| 068Z3425 | TS 2 flare×solder connection |
| 068Z3427 | TS 2 flare×solder connection |
| 068Z3429 | TS 2 flare×solder connection |
| 068Z3435 | TS 2 flare×solder connection |
| 068Z3436 | TS 2 flare×solder connection |
| 068Z3206 | TX 2 flare×flare connection |
| 068Z3207 | TX 2 flare×flare connection |
| 068Z3208 | TX 2 flare×flare connection |
| 068Z3224 | TX 2 flare×flare connection |
| 068Z3226 | TX 2 flare×flare connection |
| 068Z3228 | TX 2 flare×flare connection |
| 068Z3276 | TX 2 flare×solder connection |
| 068Z3281 | TX 2 flare×solder connection |
| 068Z3287 | TX 2 flare×solder connection |
| 068Z3302 | TX 2 flare×solder connection |
| 068Z3308 | TX 2 flare×solder connection |
| 068Z3319 | TX 2 flare×solder connection |
| 068Z3357 | TX 2 flare×solder connection |
| 068Z3361 | TX 2 flare×solder connection |
| 068Z3366 | TX 2 flare×solder connection |
| 068Z3496 | TZ 2 flare×flare connection |
| 068Z3516 | TZ 2 flare×flare connection |
| 068Z3502 | TZ 2 flare×solder connection |
| 068Z3514 | TZ 2 flare×solder connection |
| Expansion Valve | |
| Code | Type |
| 068Z3332 | TX 2 flare×solder connection,industrial packaging |
| 068Z3333 | TEX 2 flare×solder connection,industrial packaging |
| 068Z3445 | TES 2 flare×solder connection,industrial packaging |
| Adaptor | |
| 068-206066 | Adaptor |
| 068-206166 | Adaptor |
| 068-206266 | Adaptor |
| 068-206366 | Adaptor |
| 068-208166 | Adaptor |
| TE5 -55 | |
| 067B2788 | New TE 5 orifice assembly No. 0.5 |
| 067B2789 | New TE 5 orifice assembly No. 1 |
| 067B2790 | New TE 5 orifice assembly No. 2 |
| 067B2791 | New TE 5 orifice assembly No. 3 |
| 067B2792 | New TE 5 orifice assembly No. 4 |
| 067B2708 | New TE12 orifice assembly No. 5 |
| 067B2709 | New TE12 orifice assembly No. 6 |
| 067B2710 | New TE12 orifice assembly No. 7 |
| 067B2771 | New TE20 orifice assembly No. 8 |
| 067B2773 | New TE20 orifice assembly No. 9 |
| 067G2705 | New TE55 orifice assembly No. 9B |
| 067G2701 | New TE55 orifice assembly No. 10 |
| 067G2704 | New TE55 orifice assembly No. 11 |
| 067G2707 | New TE55 orifice assembly No. 12 |
| 067G2710 | New TE55 orifice assembly No. 13 |
