4HP Copeland Semi Hermetic compressor DLSGE-40X-EWL For Ice - water

4HP Copeland Semi Hermetic compressor DLSGE-40X-EWL For Ice - water

Specification

1. Copeland Semi-Hermetic compressor:DLSGE-40X-EWL
2. Applied to Freeze,Cold Storage, Ice-water
3. 4HP
4. 85Kgs/Unit
5. R134a/R404A/R507

Copeland's specification:

1.higher efficiency
2.lower sound levels
3.superior durability

• DK/DL new series Air-cooled 1.0 to 5 HP
• R134A R404A/R507 refrigerant
• DWM Copeland™ Compressors are suitable for a wide range of applications either in the form of single ompressors, condensing units or as multi-compressor equipment.
•

• Model	nom HP	Displace m3/hr	Evaporating temperature (Capctiy R404A/R507)									Electrical amp s/ph
  			-35	-30	-25	-20	-15	-10	-5	0	5	rla*	mcc*	l. r. a
  DKSJ-15X-EWL	1.5	6.3	937	1260	1635	2075	2595	3200	3905			3.2	3.5	20.4
  DLE-20X-EWL	2	9.9	871	1430	20700	2810	3665	4655	5805	7130	8655	4.6	5.7	37.6
  DLJ-30X-EWL	3	14.5	1770	2540	3425	4460	5665	7070	8705	10590	12760	6.7	8.07	53
  DLL-40X-EWL	4	18.1	2273	3330	4558	5996	7670	9615	11870	14460	17460	7.9	9.5	68.5
  DLSG-40X-EWL	4	22.5	2980	4175	5625	7300						7.4	8.9	53.4
  D2SC-65X-EWL	6.5	26.9		5100	6750	8700	10900	13500	16400	19800	23700	12.7	16.2	85.3
  D3SA-75X-AWM	7.5	32.2		5600	7650	10500	12850	16100	19800	24100	28900	14.2	17.9	82
  D3SC-100X-AWM	10	38		7150	9500	12250	15500	19300	23800	29000	35000	16.8	21.6	106
  D3SS-150X-AWM	15	49.9		10350	13550	17200	21400	26300	32000	38500	46000	23.2	30.2	125
  D4SA-200X-AWM	20	56		10650	14250	18400	23200	28800	35000	42500	51000	24.2	30.5	160
  D4SH-250X-AWM	25	70.8		13300	17600	22600	28300	3500	42500	51500	62000	31.1	40.1	192
  D4SJ-300X-AWM	30	84.7		15800*	21200	27400	34500	43000	52500	64000	76500	36.2	47.7	218
  D6SH-350X-AWM	35	106		19600*	26000	33500	42000	52000	63500	76500	92000	49.6	62.4	284
  D6SJ-400X-AWM	40	127		23100*	30500	39000	49000	60500	74000	89000	100000	55.2	71.8	347
  D6SK-500X-AWM	50	151.8		27200*	36500	47000	59500	73500	90500	109500	100000	71	94.7	415
  D8SJ600XB-1	60	181		33000	44000	56500	71500	88500	100000	13500	15800	84	107	544
  DKL20X-EWL	2	7.4	940	1330	1790	2330	2950	3700	4500			2.6	3.83	20.4
  DKSL20X-EWL	2	9.1	1390	1860	2410	3060	3820	4700	5700			3.2	4.7	20.4
  DLL30X-EWL	3	18.2	2268	3293	4503	5918						5.5	7.3	53
  D2SA-45X-EWL	4.5	22.4	3160*	4300	56500	7250	9100	11250	13700			7.4	11.4	68.5
  D3SA-75X-AWM	7.5	32.2		5600	7650	10050	12850	16100	19800	24100	28900	10.5	17.9	82
  D3SC-75X-AWM	7.5	38	5013*	6800	9000	11700	14850	18600	22900			12.4	18.7	82
  D3SS-100X-AWM	10	49.9		9950	12900	16300	20300	24900	30500			16.3	26	109
  D4SF-100X-AWM	10	56		11250	14600	18500	23200	28700	35000			16.9	27.1	105
  D4SL-150X-AWM	15	70.8		14700	18900	23900	29700	36500	44000			21.7	35.6	156
  D4ST-200X-AWM	20	84.7		17200	22400	28500	35500	44000	53500			24.2	42.4	175
  D6SL-250X-AWM	25	106		21400	27700	35000	43500	53000	64000			31.4	56.5	199
  D6ST-320X-AWM	32	127		25000	32000	40500	50500	62000	75000			39.2	62.9	255
  D6SU-400X-AWM	40	151.8		29600	38500	49000	61500	75500	92000			47.3	78	304
  D8SJ-450X-BWM	45	181		35500	46500	59000	74000	91000	100000			53.3	90.8	458
