Electronic Temperature Controller type EKC EKD EKA EKS Series

EKC 201 (for panel mounting) and EKC 301 (for DIN-rail mounting) have been specially developed for control duties in refrigeration plant so that operation, setting and programming are optimised and simplified as much as possible.

All controllers are designed for room temperature control via pump down or compressor start/stop and have been grouped into four main applications dependent on the type of defrost and its control.

EKC 201 and 301 are used for
Temperature control
Compressor control
Fan motor control
Defrost control
Alarm signalling
With only two keys, all functions can be set and programmed.
The display shows the actual room temperature, but by activating the keys the display changes
To the set or the actual temperature of the defrost sensor.

Fitting the EKC controller with a plug-in module for communication gives access to all parameters of the controller. Thus, EKC 201/301 can be included in the ADAP-KOOL® Refrigeration control systems.

The digital input can be programmed to
- receive alarm signals from an external signal source (door alarm)
- start defrost from an external clock
- transmit random alarm signals to the bus system.



ELECTRONIC CONTROLS
Part Number	Description
084B7025	EKA151 THERMOMETER 230 V
084B7027	EKC102A H/C 230V 1 RELAY
084B7030	EKC202 L/T 230V 4 RELAYS
084B7031	EKC204 L/T 230V 4 RELAYS RTC
084B7620	EKC101 M/T 230V 1 RELAY
084N0035	SENSOR PT1000
084N1163	EKS111 SENSOR 3.5M FOR EKC101
