Szczegóły Produktu:
Zapłata:
|
| Applicable refrigerant: | HCFC and HFC | Applicable medium temperature: | -40~+150 |
|---|---|---|---|
| tube end: | copper | Application: | Refrigeration Parts |
| wire braid: | stainless steel | testing pressure: | 525-2500Psig |
| application pressure: | 175-500Psig | Type: | vibration absorber |
| High Light: | refrigeration and air conditioning tools and equipment,refrigerator tools |
||
|
Type
|
Size | Outline Dimension | (MPa)Max. Working Pressure |
(mm)Min. Bending Radius |
|||
| A | L | D | (Rj) Static |
(Rd) Dynamic |
|||
| VAF-038-10 | 3/8 | 20 | 210 | 9.7 0 +0.15 | 4.2 | 80 | 180 |
| VAF-012-12 | 1/2 | 23 | 230 | 12.8 0 +0.2 | 4.2 | 95 | 215 |
| VAF-058-16 | 5/8 | 25 | 250 | 16.1 0 +0.2 | 4.2 | 120 | 270 |
| VAF-034-19 | 3/4 | 28 | 260 | 19.1 0 +0.2 | 4.2 | 145 | 325 |
| VAF-078-22 | 7/8 | 35 | 300 | 22.3 0 +0.2 | 4.2 | 160 | 360 |
| VAF-001-25 | 1 | 35 | 330 | 25.6 0 +0.2 | 4.2 | 175 | 400 |
| VAF-118-28 | 1 1/8 | 35 | 330 | 28.7 0 +0.2 | 4.2 | 175 | 400 |
| VAF-114-32 | 1 1/4 | 50 | 400 | 32.1 0 +0.2 | 3.5 | 225 | 510 |
| VAF-138-35 | 1 3/8 | 50 | 400 | 35.2 0 +0.2 | 3.5 | 225 | 510 |
| VAF-158-42 | 1 5/8 | 55 | 400 | 41.5 0 +0.25 | 2.5 | 280 | 640 |
| VAF-218-54 | 2 1/8 | 65 | 520 | 54.2 0 +0.25 | 2.5 | 350 | 800 |
| VAF-258-67 | 2 5/8 | 76 | 610 | 66.8 0 +0.25 | 2 | 390 | 845 |
| VAF-318-79 | 3 1/8 | 88 | 680 | 79.6 0 +0.25 | 2 | 480 | 1000 |
